Móðurborð AM4 Gigabyte B550M DS3H RGB mATX

GIGABYTE B550M DS3H Socket AM4/ AMD B550/ DDR4/ SATA3&USB3.2/ M.2/ Micro ATX Motherboard

  • Mfr Part Number:B550M DS3H
  • CPU:AMD Socket AM4, support for: AMD Ryzen 5000 Series/ 3rd Gen Ryzen and 3rd Gen Ryzen with Radeon Graphics Processors
  • Chipset:AMD B550
  • Memory:
    • 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
    • 3rd Gen AMD Ryzen Processors:
    • - Support for DDR4 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 MHz memory modules
    • 3rd Gen AMD Ryzen with Radeon Graphics processors:
    • - Support for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 MHz memory modules
    • Dual channel memory architecture
    • Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
    • Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    • Support for Extreme Memory Profile (XMP) memory modules
  • Onboard Graphics:
    • Integrated in the 3rd Generation AMD Ryzen with Radeon Graphics processors:
      • - 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
      • - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
    • Maximum shared memory of 16 GB
  • Audio:
    • Realtek ALC887 codec
    • High Definition Audio
    • 2/4/5.1/7.1-channel
  • LAN:Realtek GbE LAN chip (1000 Mbit/100 Mbit)
  • Expansion Slots:
    • 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
    • - 3rd Generation AMD Ryzen processors support PCIe 4.0 x16 mode
    • - 3rd Generation AMD Ryzen with Radeon Graphics processors support PCIe 3.0 x16 mode
    • 1 x PCI Express x16 slot (PCIEX4), integrated in the Chipset:
    • - Supporting PCIe 3.0 x4 mode
    • 1 x PCI Express x1 slot (PCIEX1), integrated in the Chipset:
    • - Supporting PCIe 3.0 x1 mode
  • Storage Interface:
    • 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs:
    • - 3rd Generation AMD Ryzen processors support SATA and PCIe 4.0 x4/x2 SSDs
    • - 3rd Generation AMD Ryzen with Radeon Graphics processors support SATA and PCIe 3.0 x4/x2 SSDs
    • 1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2260/2280SSDs:
    • - Supporting SATA and PCIe 3.0 x2 SSDs
    • 4 x SATA 6Gb/s connectors, integrated in the Chipset:
    • - Support for RAID 0, RAID 1, and RAID 10
  • USB:
    • CPU:
    • - 4 x USB 3.2 Gen 1 ports on the back panel
    • Chipset:
    • - 2 x USB 3.2 Gen 1 ports available through the internal USB header
    • - 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2ports available through the internal USB headers)
  • Internal I/O Connectors:
    • 1 x 24-pin ATX main power connector
    • 1 x 8-pin ATX 12V power connector
    • 1 x CPU fan header
    • 2 x system fan headers
    • 2 x addressable LED strip headers
    • 2 x RGB LED strip headers
    • 1 x CPU cooler LED strip/RGB LED strip header
    • 2 x M.2 Socket 3 connectors
    • 4 x SATA 6Gb/s connectors
    • 1 x front panel header
    • 1 x front panel audio header
    • 1 x USB 3.2 Gen 1 header
    • 1 x USB 2.0/1.1 header
    • 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
    • 1 x serial port header
    • 1 x Clear CMOS jumper
    • 1 x Q-Flash Plus button
  • Back Panel Connectors:
    • 1 x PS/2 keyboard/mouse port
    • 1 x DVI-D port
    • 1 x HDMI port
    • 4 x USB 3.2 Gen 1 ports
    • 4 x USB 2.0/1.1 ports
    • 1 x RJ-45 port
    • 3 x audio jacks
    • I/O Controller:iTE I/O Controller Chip
  • H/W Monitoring:
    • Voltage detection
    • Temperature detection
    • Fan speed detection
    • Overheating warning
    • Fan fail warning
    • Fan speed control
  • BIOS:
    • 1 x 256 Mbit flash
    • Use of licensed AMI UEFI BIOS
    • PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
  • Unique Features:
    • Support for APP Center
    • - @BIOS
    • - EasyTune
    • - Fast Boot
    • - Game Boost
    • - ON/OFF Charge
    • - RGB Fusion
    • -Smart Backup
    • -System Information Viewer
    • Support for Q-Flash Plus
    • Support for Q-Flash
    • Support for Xpress Install
  • Bundled Software:
    • NortonInternet Security (OEM version)
    • Realtek8118Gaming LAN Bandwidth Control Utility
  • Operating System:Support for Windows 10 64-bit
  • Form Factor:Micro ATX Form Factor; 24.4cm x 24.4cm
  • *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country. All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers.
Framleiðandi: Gigabyte
Framl.númer: B550M DS3H
Vörunúmer: 7291

Til á lager

Vandað móðurborð fyrir þriðju og 5000 seriuna af AMD Ryzen örgjörvunum. Styður einnig flestar gerðir 3. kynslóð AMD Ryzen. Styður allt að 128GB vinnsluminni.


Frí heimsending
10% Afsláttur
Verð: 21.990 kr
Verð: 19.791 kr
