Stýrispjald LSI Broadcom Megaraid 9361-8i SGL
Data center, cloud and high-performance computing environments not only require large amounts of storage capacity, they also must provide the data protection and performance today’s applications and end users demand. The MegaRAID SAS 9361-8i 12Gb/s SAS and SATA RAID controller card addresses these needs by delivering proven performance and RAID data protection for a range of server storage applications.
| RAID 0/1/10/5/6/50/60, PCIe 3.0 x8, 8 Ports Broadcom MegaRAID SAS 9361-8i, SAS, Serial ATA, PCI Express x8, 0, 1, 5, 6, 10, 50, 60, 12 Gbit/s, 1024 MB, DDR3 |
|
| Ports & interfaces | |
|---|---|
| Supported storage drive interfaces: | SAS, Serial ATA |
| Host interface: | PCI Express x8 |
| PCI Express slots version: | 3.0 |
| Internal SAS ports: | 8 |
| Performance | |
|---|---|
| RAID levels: | 0, 1, 5, 6, 10, 50, 60 |
| RAID Level Migration: | Yes |
| Data transfer rate: | 12 Gbit/s |
| SSD support: | Yes |
| Internal memory: | 1024 MB |
| Internal memory type: | DDR3 |
| Memory clock speed: | 1866 MHz |
| S.M.A.R.T. support: | Yes |
| Number of devices supported: | 240 |
| Online Capacity Expansion: | Yes |
| Mean time between failures (MTBF): | 1343187 h |
| Certification: | EN55022, EN55024, EN60950, EN 61000-3-2, EN 61000-3-3; FCC Class A, Class B; UL1950; UL; CSA C22.2; VCCI; RRL for MIC; BSMI; C-tick |
| System requirements | |
|---|---|
| Windows operating systems supported: | Yes |
| Linux operating systems supported: | Yes |
| Operational conditions | |
|---|---|
| Operating temperature (T-T): | 10 - 55 °C |
| Storage temperature (T-T): | -45 - 105 °C |
| Operating relative humidity (H-H): | 20 - 80% |
| Storage relative humidity (H-H): | 5 - 95% |
| Logistics data | |
|---|---|
| Harmonized System (HS) code: | 84733080 |
