PoE Splitter TP-Link TL-POE10R 1Gbit 5V/12V
TP-LINK’s PoE Splitter TL-POE10R fully complies with IEEE 802.3af standard. It can receive power and data from all IEEE 802.3af PoE compliant PSE (Power Source Equipment) or PoE Injector, such as TP-LINK's TL-SG3424P, TL-SF1008P, TL-POE150S or other equivalent products, then split electric power and data into two cables, so you can install the non-PoE devices like Wireless Access Points, IP Cameras or IP Phones, in remote location where there are no power lines or outlets, where you wish to fix these devices.
| IEEE 802.3/802.3u/802.3ab/802.3af, 10/100/1000Mbps, PoE TP-Link TL-POE10R v4, Gigabit Ethernet, 10,100,1000 Mbit/s, 10/100/1000, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u, Cat3, Cat5, Cat5e, Black |
|
| Network | |
|---|---|
| Ethernet interface type: | Gigabit Ethernet |
| Ethernet LAN data rates: | 10,100,1000 Mbit/s |
| Cabling technology: | 10/100/1000 |
| Power over Ethernet (PoE): | Yes |
| Networking standards: | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u |
| Cable types supported: | Cat3, Cat5, Cat5e |
| Features | |
|---|---|
| Product colour: | Black |
| Plug and Play: | Yes |
| LED indicators: | Power |
| Ports & interfaces | |
|---|---|
| Ethernet LAN (RJ-45) ports: | 2 |
| RJ-45 input ports: | 1 |
| RJ-45 output ports: | 1 |
| Power | |
|---|---|
| Input voltage: | 5, 9, 12 V |
| Input current: | 1, 2 A |
| Certificates | |
|---|---|
| Certification: | FCC, CE |
| Operational conditions | |
|---|---|
| Operating temperature (T-T): | 0 - 40 °C |
| Operating relative humidity (H-H): | 10 - 90% |
| Storage temperature (T-T): | -40 - 70 °C |
| Storage relative humidity (H-H): | 5 - 90% |
| Weight & dimensions | |
|---|---|
| Width: | 81 mm |
| Depth: | 52 mm |
| Height: | 24 mm |
| Packaging content | |
|---|---|
| Number of products included: | 1 pc(s) |
| Quick installation guide: | Yes |
| Packaging data | |
|---|---|
| Package width: | 165 mm |
| Package depth: | 198 mm |
| Package height: | 65 mm |
| Package weight: | 230 g |
| Package type: | Box |
