Örgjörvakæling Inter-Tech LGA1700/1851 Q-5 2HE 2U
High-quality CPU cooler to Intel® standard
GENERAL DATA
- CPU Sockets Intel® Socket LGA 1700
- TDP up to 185 Watts
- Solution 2U Server
- Cooling type active
- Material Copper Base & Aluminum Fins with Heat Pipe embedded
- Fan Dimensions ∅ 60 x 25mm
- Rated Voltage 12V
- Bearing 2 Ball Bearing
- Fan Speed At 0~20%: 1600 ± 200 RPM
- At 50%: 4000 ± 10% RPM
- At 100%: 8000 RPM
- Fan Power At 0~20%: 1.20 Watts
- At 50%: 2.28 Watts
- At 100%: 7.20 Watts
- Air Flow At 0~20%: 9.28 CFM
- At 50%: 23.21 CFM
- At 100%: 46.41 CFM
- Air Pressure At 0~20%: 0.76 mm-H2O
- At 50%: 4.76 mm-H2O
- At 100%: 19.04 mm-H2O
- Noise Level At 0~20%: 18.00 dBA
- At 50%: 37.89 dBA
- At 100%: 52.94 dBA
- Fan Connector 4Pin PWM
OTHER DATA
- Dimension 90.7 x 85.0 x 65.1mm
- Warranty 24 months
SCOPE OF DELIVERY & FEATURES
- Scope of delivery
- CPU-Cooler
- Retail packaging
- Backplate
- Thermal Grease Shin-Etsu 7762 Pre-printed
LOGISTICAL DATA
Shipping Unit 1 Pcs
Weight net = 0.515kgs
Item number 88885584
| 150 W, ∅ 60 x 25mm, 12V, 8000 RPM, 46.41 CFM, 52.94 dBA, Copper Inter-Tech Q-5, Heatsink/Radiator, 6 cm, Black, Silver |
|
| Performance | |
|---|---|
| Suitable location: | Processor |
| Type: | Heatsink/Radiator |
| Fan diameter: | 6 cm |
| Supported processor sockets: | LGA 1700 |
| Noise level (low speed): | 18 dB |
| Noise level (high speed): | 52.94 dB |
| Minimum airflow (imperial): | 9.28 cfm |
| Maximum airflow: | 46.41 cfm |
| Minimum air pressure: | 0.76 mmH2O |
| Maximum air pressure: | 19.04 mmH2O |
| Bearing type: | Ball bearing |
| Quantity per pack: | 1 pc(s) |
| Fan speed (min): | 1600 RPM |
| Fan speed (max): | 8000 RPM |
| Design | |
|---|---|
| Product colour: | Black, Silver |
| Material: | Aluminium, Copper |
| Base plate material: | Copper |
| Number of fans: | 1 fan(s) |
| Fins material: | Aluminium |
| Fan connector: | 4-pin |
| Power | |
|---|---|
| Rated voltage: | 12 V |
| Fan power consumption: | 7.2 W |
| Thermal Design Power (TDP): | 150 W |
| Weight & dimensions | |
|---|---|
| Width: | 90.7 mm |
| Depth: | 85 mm |
| Height: | 65.1 mm |
| Weight: | 515 g |
| Fan thickness: | 2.5 cm |
| Packaging content | |
|---|---|
| Thermal pad included: | Yes |
| Logistics data | |
|---|---|
| Harmonized System (HS) code: | 84733080 |
