• Micro-ATX H610 business motherboard with enhanced security, reliability, manageability and serviceability
• Intel® LGA 1700 socket: Ready for 12th & 13th Gen Intel Core™ processors
• ASUS CSM program: A stable motherboard supply, end-of-life notifications, and IT software for business motherboards
• ASUS Control Center Express: Integrated IT monitoring and management software that simplifies enterprise-level system administration
• Enhanced system security: A self-recovering BIOS, and TPM to safeguard PCs
• Consistent and reliable performance: High-quality components and rigorous testing to help ensure durability in harsh environments
• Efficient management and customization: An event log and commercial BIOS kit to enable easy maintenance
• Better serviceability: Q-LED diagnostic display and COM debug header to facilitate building and support processes
• Ultrafast connectivity: PCIe 5.0, DDDR 5, USB 3.2 Gen 2

ASUS Pro business motherboards provide enhanced features to smooth your IT operations, including comprehensive system protection, 24/7 stability and reliability and an improved management suite for easier customization. Known as the world's biggest and best-known motherboard brand, ASUS provides world-class after-sales service and guaranteed long-term availability to maximize your investment over the product life cycle and offers a high-quality, TCO-optimized solution for your business computing-needs.

ASUS Corporate Stable Model
ASUS Corporate Stable Model (CSM) is a commercial program designed to provide stable and reliable motherboards. Offering up to 36-month product lifecycle support and 6-month end-of-life notice to allow sufficient lead times for your organization to get ready for product transitions. Each purchase of an ASUS CSM motherboard comes with ASUS Control Center Express - server-grade IT management software.

Specifications

• CPU:
  • Intel® Socket LGA1700 for 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors
  • Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
  • * Refer to www.asus.com for CPU support list.
  • ** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.
• Chipset: Intel® H610 Chipset
• Memory
  • 2 x DIMM, Max. 64GB, DDR5 4800 Non-ECC, Un-buffered Memory*
  • Dual Channel Memory Architecture
  • Supports Intel® Extreme Memory Profile (XMP)
  • *Supported memory types, data rate(Speed), and number of DRAM module vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list.
• Graphics
  • 1 x DisplayPort**
  • 1 x D-Sub port
  • 1 x HDMI® port***
  • 1 x DVI-D port
  • * Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
  • ** Supports max. 4K@60Hz as specified in DisplayPort 1.4.
  • *** Supports 4K@60Hz as specified in HDMI 2.1.
  • **** Supports up to 3 displays simultaneously.
• Expansion Slots
  • Intel® 12th Gen Processors
    • 1 x PCIe 5.0 x16 slot
  • Intel® H610 Chipset
    • 2 x PCIe 3.0 x1 slots
    • 1 x PCI
• Storage
  • Total supports 1 x M.2 slot and 4 x SATA 6Gb/s ports
  • Intel® H610 Chipset
    • M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 mode)
    • 4 x SATA 6Gb/s ports
• Ethernet
  • 1 x Intel® 1Gb Ethernet
  • ASUS LANGuard
• USB
  • Rear USB (Total 4 ports)
    • 2 x USB 3.2 Gen 2 ports (2 x Type-A)
    • 2 x USB 2.0 ports (2 x Type-A)
  • Front USB (Total 6 ports)
    • 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
    • 2 x USB 2.0 headers support additional 4 USB 2.0 ports
• Audio
  • Realtek 7.1 Surround Sound High Definition Audio CODEC*
  • - Supports: Jack-detection, Front Panel Jack-retasking
  • - Supports up to 24-Bit/192 kHz playback
  • * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
• Back Panel I/O Ports
  • 2 x USB 3.2 Gen 2 ports (2 x Type-A)
  • 2 x USB 2.0 ports (2 x Type-A)
  • 1 x DisplayPort
  • 1 x HDMI® port
  • 1 x D-Sub port
  • 1 x DVI-D port
  • 1 x Intel® 1Gb Ethernet
  • 3 x Audio jacks
  • 1 x PS/2 keyboard (purple) port
  • 1 x PS/2 mouse (green) port
  • 1 x COM port
• Internal I/O Connectors
  • Fan and cooling related
  • 1 x 4-pin CPU Fan header
  • 1 x 4-pin Chassis Fan header
  • Power related
  • 1 x 24-pin Main Power connector
  • 1 x 8-pin +12V Power connector
  • Storage related
  • 1 x M.2 slots (Key M)
  • 4 x SATA 6Gb/s ports
• USB
  • 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
  • 2 x USB 2.0 headers support additional 4 USB 2.0 ports
• Miscellaneous
  • 1 x Clear CMOS header
  • 1 x Chassis Intrude header
  • 1 x COM Port headers
  • 1 x Front Panel Audio header (AAFP)
  • 1 x COM debug header
  • 1 x LPT header
  • 1 x Mono-out header(with Amp IC)
  • 1 x SMBUS header
  • 1 x Speaker header
  • 1 x SPI TPM header (14-1pin)
  • 1 x 10-1 pin System Panel header
• Special Features
  • ASUS EZ DIY
  • - Box Headers
  • Bespoke Motherboard Design & Business Focused Features
  • - Q-LED Core
  • - ASUS Self Recovering BIOS
  • - ASUS Event Log
  • - ASUS Commercial BIOS kit
  • - Anti-Moisture
  • - 24/7 Reliability
  • - Overcurrent Protection
• Software Features
  • ASUS Exclusive Software
  • IT Management software supported
  • - ASUS Control Center Express(ACCE)
• BIOS
  • 128Mb Flash ROM
• Manageability
  • WOL by PME, PXE
• Accessories
  • Cables
  • 2 x SATA 6Gb/s cables
• Miscellaneous
  • 1 x I/O Shield
  • 1 x M.2 SSD screw package
• Installation Media
  • 1 x Support DVD
• Documentation
  • 1 x ACC Express Activation Key Card
  • 1 x User guide
• Operating System
  • Windows® 11 64-bit, Windows® 10 64-bit
• Form Factor
  • mATX Form Factor
  • 9.6 inch x 8.7 inch (24.4 cm x 22 cm)
