Fartölvudokka Icybox USB-C IB-DK2106a-CPD PD100W

Framleiðandi: Icy Box
Framl.númer: IB-DK2106a-CPD
Vörunúmer: 12209

Til á lager

Icy Box IB-DK2106a-CPD er fjölhæf fartölvudokka sem býður upp á 11 tengimöguleika í einu tæki. Tengdu skjái, USB-tæki, netkapal, hljóð og minniskort með einum USB-C tengli. Styður allt að 100W hleðslu og virkar án rekla. Frábær lausn fyrir heimaskrifstofuna, vinnuna eða ferðalagið – einföld og snyrtileg lausn.


Frí heimsending
Verð: 18.990 kr

Tengimöguleikar (11-in-1)

  • USB tengi:
    • 3× USB 3.0 Type-A (allt að 5 Gbit/s)
    • 1× USB-C (Power Delivery, allt að 100 W; eingöngu fyrir hleðslu)
  • Skjátengi:
    • 2× HDMI (allt að 3840×2160 við 30 Hz)
      • 1× VGA (allt að 1920×1200 við 60 Hz)
  • Nettenging:
    • 1× RJ-45 Gigabit Ethernet (10/100/1000 Mbps)
  • Minniskortalesari:
    • 1× SD (SD 3.0, UHS-I)
    • 1× microSD (UHS-I)
    • Athugið: Styður aðeins eitt kort í einu (Single-LUN)
  • Hljóðtengi:
    • 1× 3.5 mm samsett hljóðtengi (heyrnartól og hljóðnemi)
  • Tæknilýsing
    • Aflgjafi: USB-C með Power Delivery (allt að 100 W; 20 V @ 5 A)
    • Gagnahraði: Allt að 5 Gbit/s
    • Mál: 277 × 75 × 17 mm
    • Þyngd: 290 g
    • Efni: Ál og plast
    • Litur: Dökkgrár / svartur
    • USB-C snúra: Innbyggð, 50 cm með nylon-umgjörð
    • Kæling: Passív (enginn viftuhljóð)
  • Samhæfni við stýrikerfi
    • Windows: Já
    • macOS: Já
    • ChromeOS: Já
    • Athugið: Engin þörf á auka rekli (plug & play) ef tölvan styður DisplayPort Alt Mode
  • Athugun
    • Til að nýta skjátengingu þarf tölvan að styðja DisplayPort Alt Mode yfir USB-C.
    • Stuðningur við Multi-Stream Transport (MST) er háður stýrikerfi og skjákorti.
  • Innihald pakkningar
    • 1× Icy Box IB-DK2106a-CPD tengikassi
      • 1× Notendahandbók



More Options
DockingStations not only offer users a way to quickly transition from one working environment to another via a single cable, but they can also add additional functionality and capabilities to notebook designs that are increasingly slim and with limited interface option.

USB Type-C®
The Type-C® connection offers incredible versatility. It combines data transmission, video output, and power in a single, compact port. The integration of USB Type-C® makes the connection even more practical, as it has a twist-proof connection as its physical feature - making it a truly universal connection.

Easy connection - multiple benefits
Perfectly combines a high-quality appearance and efficient technology with a very compact size. The premium aluminum DockingStation does not only look good but also offers high comfort while using. This solution is suited for any location such as private or office areas.

PERFECTLY CONNECTED: ICY BOX docking station with 3x USB Type-A USB 3.0, 2x HDMI®, 1x VGA, 1x card reader for SD/microSD cards, 1x Gigabit LAN RJ45, 1x audio in/out and a USB Type-C® charging port.
ERGONOMIC WORKING: The IB-DK2106a-CPD docking station also serves as an elevation for your laptop. This creates an ergonomic angle for the keyboard and allows device heat to dissipate more efficiently.
PLUG & PLAY: There is no need to install drivers. Simply plug in the integrated nylon-sheathed USB Type-C® cable and your laptop becomes a multi-display workstation.
POWER DELIVERY: The Type-C connector of the docking station serves as a pure charging port (no data transfer) with a power of up to 100 W (20 V@5 A). A power supply unit must be connected to the laptop for this purpose.
CONNECTING MONITORS: For more effective work, you can connect two monitors. Use either the two HDMI® connections or one HDMI® connection in combination with the VGA interface.



11-in-1 via USB Type-C
ICY BOX IB-DK2106a-CPD, Wired, USB 3.2 Gen 1 (3.1 Gen 1) Type-C, 100 W, 3.5 mm, 10,100,1000 Mbit/s, Anthracite, Black
  • Wired
  • Host interface: USB 3.2 Gen 1 (3.1 Gen 1) Type-C
  • USB Power Delivery (USB PD)
  • Ethernet LAN 10,100,1000 Mbit/s
  • MicroSD (TransFlash), SD
Ports & interfaces
Connectivity technology:Wired
Host interface:USB 3.2 Gen 1 (3.1 Gen 1) Type-C
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity:1
USB Power Delivery (USB PD):Yes
USB Power Delivery up to:100 W
HDMI ports quantity:2
VGA (D-Sub) ports quantity:1
Microphone in:Yes
Combo headphone/mic port:Yes
Headphone outputs:1
Headphone connectivity:3.5 mm
Network
Ethernet LAN:Yes
Ethernet LAN (RJ-45) ports:1
Ethernet LAN data rates:10,100,1000 Mbit/s
Performance
Card reader integrated:Yes
Compatible memory cards:MicroSD (TransFlash), SD
Data transfer rate:5 Gbit/s
HD type:4K Ultra HD
Maximum digital resolution:3840 x 2160 pixels
Maximum analog resolution:1920 x 1200 pixels
Number of displays supported:3
Product colour:Anthracite, Black
UASP support:Yes
Housing material:Aluminium, Plastic
Country of origin:China
Power
Power source type:USB
Output voltage:5 V
Output current:1.5 A
Software
Windows operating systems supported:Windows 10
Weight & dimensions
Width:277 mm
Depth:75 mm
Height:17 mm
Weight:290 g
Packaging data
Quantity per pack:1 pc(s)
Package width:130 mm
Package depth:30 mm
Package height:340 mm
Package weight:420 g
Packaging content
Manual:Yes
Logistics data
Products per master (outer) case:20 pc(s)
Master (outer) case width:285 mm
Master (outer) case length:305 mm
Master (outer) case height:365 mm
Master (outer) case gross weight:9.6 kg
