TP-LINK TL-PA8010PKIT - 1.2GB Powerline with Pass-through (1 LAN port) Net yfir rafmagn TP-Link 1200M TL-PA8010P KIT
TP-LINK TL-PA8010PKIT - 1 200M (1.2GB) Powerline with Pass-through (1 LAN port)
Description
Description
-
HomePlug AV2 standard compliant, high-speed data transfer rates of up to 1300Mbps, supports all your online needs
-
Line-Neutral/Line-Ground 2×2 MIMO with Beamforming ensures larger range, higher transmission capacity and more stable connections
-
Gigabit port provides secure wired networks for desktops, smart TVs or games consoles
-
Integrated power socket ensures no power outlet goes to waste
Product Description: TP-Link TL-PA8010P KIT - Starter Kit - bridge - wall-pluggable
Device Type: Bridge
Enclosure Type: Wall-pluggable
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet, HomePlug AV (HPAV), HomePlug AV (HPAV) 2.0
Data Transfer Rate: 1.2 Gbps
Features: 2T2R MIMO technology
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, HomePlug AV, HomePlug AV 2.0, IEEE 1901
Power: 220 VAC (50 Hz)
Dimensions (WxDxH): 13.1 cm x 7.2 cm x 4.2 cm
System Requirements: Apple MacOS, Linux, Microsoft Windows Server 2003, Microsoft Windows 2000/XP/Vista/7, Windows 8, Windows 10
Localisation: United Kingdom, Europe
Device Type: Bridge
Enclosure Type: Wall-pluggable
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet, HomePlug AV (HPAV), HomePlug AV (HPAV) 2.0
Data Transfer Rate: 1.2 Gbps
Features: 2T2R MIMO technology
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, HomePlug AV, HomePlug AV 2.0, IEEE 1901
Power: 220 VAC (50 Hz)
Dimensions (WxDxH): 13.1 cm x 7.2 cm x 4.2 cm
System Requirements: Apple MacOS, Linux, Microsoft Windows Server 2003, Microsoft Windows 2000/XP/Vista/7, Windows 8, Windows 10
Localisation: United Kingdom, Europe
Technical description
General
Device Type: Bridge
Enclosure Type: Wall-pluggable
Connectivity Technology: Wired
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet, HomePlug AV (HPAV), HomePlug AV (HPAV) 2.0
Data Transfer Rate: 1.2 Gbps
Max. Range Indoors: 300 m
Encryption Algorithm: 128-bit AES
Features: 2T2R MIMO technology
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, HomePlug AV, HomePlug AV 2.0, IEEE 1901, Plug and Play, RoHS
Status Indicators: Power, link/activity
Line Properties
Line Coding Format: OFDM
Device Type: Bridge
Enclosure Type: Wall-pluggable
Connectivity Technology: Wired
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet, HomePlug AV (HPAV), HomePlug AV (HPAV) 2.0
Data Transfer Rate: 1.2 Gbps
Max. Range Indoors: 300 m
Encryption Algorithm: 128-bit AES
Features: 2T2R MIMO technology
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, HomePlug AV, HomePlug AV 2.0, IEEE 1901, Plug and Play, RoHS
Status Indicators: Power, link/activity
Line Properties
Line Coding Format: OFDM
Expansion / Connectivity
Interfaces: LAN: 1 x HomePlug AV, LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45
Power
Power Device: Internal power supply
Voltage Required: 220 VAC (50 Hz)
Power Consumption Operational: 6 Watt
Interfaces: LAN: 1 x HomePlug AV, LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45
Power
Power Device: Internal power supply
Voltage Required: 220 VAC (50 Hz)
Power Consumption Operational: 6 Watt
Miscellaneous
Cables Included: 1 x network cable - 2 m
Localisation: United Kingdom, Europe
Cables Included: 1 x network cable - 2 m
Localisation: United Kingdom, Europe
Software / System Requirements
Software Included: Drivers & Utilities
OS Required: Apple MacOS, Linux, Microsoft Windows Server 2003, Microsoft Windows 2000/XP/Vista/7, Windows 8, Windows 10
Software Included: Drivers & Utilities
OS Required: Apple MacOS, Linux, Microsoft Windows Server 2003, Microsoft Windows 2000/XP/Vista/7, Windows 8, Windows 10
Dimensions & Weight
Width: 13.1 cm, Depth: 7.2 cm, Height: 4.2 cm
Width: 13.1 cm, Depth: 7.2 cm, Height: 4.2 cm
Environmental Parameters
Min. Operating Temperature: 0 °C
Max. Operating Temperature: 40 °C
Humidity Range Operating: 10 - 90% (non-condensing)
Min. Operating Temperature: 0 °C
Max. Operating Temperature: 40 °C
Humidity Range Operating: 10 - 90% (non-condensing)
