Processor Intel 1700 i5-12400 6C/12T UHD730
Intel S1700 CORE i5 12400 TRAY 6x2,5 65W GEN12
Specification
Processor specifics
Intel® Hyper-Threading Technology (Intel® HT Technology): Yes
Intel® Turbo Boost Technology: 2.0
Intel® Quick Sync Video Technology: Yes
Intel® Clear Video HD Technology for (Intel® CVT HD): Yes
Intel® AES New Instructions (Intel® AES-NI): Yes
Improved Intel SpeedStep Technology: Yes
Intel® Speed Shift Technology: Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0: Yes
Intel® Control-flow Enforcement Technology (CET): Yes
Intel® Thread Director: No
Intel® VT-x with Extended Page Tables (EPT): Yes
Intel® Secure Key: Yes
Intel® OS Guard: Yes
Intel® 64: Yes
Intel® Virtualization Technology (VT-X): Yes
Intel® Virtualization Technology for Direct I/O (VT-d): Yes
Intel Turbo Boost Max Technology 3.0: No
Intel® Optane™ memory ready: Yes
Intel® Boot Guard: Yes
Intel® Deep Learning Boost (Intel® DL Boost): Yes
Intel® Volume Management Device (VMD): Yes
Mode-based Execute Control (MBE): Yes
Processor
Processor family: 12th Gen Intel® Core™ i5 processors
Number of CPU cores: 6
Processor socket: LGA 1700
Processor manufacturer: Intel
Processor: i5-12400
Processor Operating Modes: 64-bit
Processor threads: 12
Performance cores: 6
Processor Boost Frequency: 4.4GHz
Power core boost frequency: 4.4GHz
Power Fundamental frequency of the core: 2.5GHz
Processor cache: 18MB
Processor cache type: Smart cache
Base performance of the processor: 65W
Maximum turbo performance: 117 w
Maximum number of DMI tracks: 8th
Memory bandwidth supported by the processor (max).: 76.8GB/s
Processor code name: Alder Lake
Storage
Memory channels: Dual channel
Maximum internal memory supported by the processor: 128GB
Memory types supported by the processor: DDR4 SDRAM,DDR5 SDRAM
Memory bandwidth (max): 76.8GB/s
Other functions
RAM memory maximum: 128GB
Graphic output: eDP 1.4b, DP 1.4a, HDMI 2.1
Graphic
Graphic
Built-in graphics adapters: Yes
Separate graphics adapter: No
On-board graphics adapter model: Intel UHD Graphics 730
Dedicated graphics adapter model: Not available
On-board graphics adapter supported outputs: Embedded DisplayPort (eDP) 1.4b,DisplayPort 1.4a,HDMI 2.1
On-board graphics adapter base frequency: 300MHz
Maximum dynamic frequency of the on-board graphics adapters: 1450MHz
Number of supported displays (on-board graphics): 4
On-board graphics adapter DirectX version: 12.0
On-board graphics adapter OpenGL version: 4.5
Maximum resolution of the on-board graphics adapter (DisplayPort): 7680 x 4320 pixels
Maximum resolution of the on-board graphics adapter (eDP - integrated flat screen): 5120 x 3200 pixels
Integrated graphics adapter maximum resolution (HDMI): 4096 x 2160 pixels
Refresh rate of the on-board graphics adapter at maximum resolution (DisplayPort): 60Hz
Refresh rate of the on-board graphics adapter at maximum resolution (eDP - integrated flat screen): 120Hz
Refresh rate of the on-board graphics adapter at maximum resolution (HDMI): 60Hz
On-board graphics adapter Device ID: 0x4692 / 0x4682
Number of calculators: 24
Multi format codec engines: 1
Features
Execute disable bit: Yes
Idle states: Yes
Thermal Monitoring Technologies: Yes
Market segment: Desktop
Terms of Use: PC / client / tablet
Maximum number of PCI Express lanes: 20
PCI Express slots version: 5.0,4.0
PCI Express configurations: 1x16+1x4,2x8+1x4
Supported Instruction Sets: SSE4.1,SSE4.2,AVX 2.0
Scalability: 1S
CPU configuration (max): 1
Embedded options available: No
Direct Media Interface (DMI) revision: 4.0
Harmonized system code: 8542310001
Export Control Classification Number (ECCN): 5A992CN3
Commodity Classification System for Automated Tracking (CCATS): G167599
Technical details
OpenCL version: 2.1
Target market: Gaming
Start date: Q122
Status: Launched
Operating conditions
Conjunction: 100 ºC
Weight and dimensions
Processor Package Size: 45 x 37.5mm
Processor Package Size: 45 x 37.5mm
